Solid Carbide 2/3/4 Flute End Mill Long Neck Type
2/3/4 Flute
Spiral
High Speed Cutting
Cast Iron, Alloy Steel, Tool Steel,Stainless Steel, High-temp Alloys, Titanium Alloys, Non-ferrous Alloys
TiAlN, TiSiN, Nano
0.005-0.01
Stub, Standard, Extra-Long, 38-330mm
Availability: | |
---|---|
Quantity: | |
Model No. | Flute Diameter (mm) | Flute length (mm) | Effective Length (mm) | Shank Diameter (mm) | Overall length (mm) |
D0.4*0.8*2*D4*50 | 0.4 | 0.8 | 2 | 4 | 50 |
D0.4*0.8*4*D4*50 | 0.4 | 0.8 | 4 | 4 | 50 |
D0.5*1*2*D4*50 | 0.5 | 1 | 2 | 4 | 50 |
D0.5*1*4*D4*50 | 0.5 | 1 | 4 | 4 | 50 |
D0.5*1*6*D4*50 | 0.5 | 1 | 6 | 4 | 50 |
D0.6*1.2*2*D4*50 | 0.6 | 1.2 | 2 | 4 | 50 |
D0.6*1.2*4*D4*50 | 0.6 | 1.2 | 4 | 4 | 50 |
D0.6*1.2*6*D4*50 | 0.6 | 1.2 | 6 | 4 | 50 |
D0.6*1.2*8*D4*50 | 0.6 | 1.2 | 8 | 4 | 50 |
D0.8*1.6*3*D4*50 | 0.8 | 1.6 | 3 | 4 | 50 |
D0.8*1.6*4*D4*50 | 0.8 | 1.6 | 4 | 4 | 50 |
D0.8*1.6*6*D4*50 | 0.8 | 1.6 | 6 | 4 | 50 |
D0.8*1.6*8*D4*50 | 0.8 | 1.6 | 8 | 4 | 50 |
D0.8*1.6*10*D4*50 | 0.8 | 1.6 | 10 | 4 | 50 |
D1*2*6*D4*50 | 1.0 | 2 | 6 | 4 | 50 |
D1*2*8*D4*50 | 1.0 | 2 | 8 | 4 | 50 |
D1*2*10*D4*50 | 1.0 | 2 | 10 | 4 | 50 |
D1*2*12*D4*50 | 1.0 | 2 | 12 | 4 | 50 |
D1.5*3*6*D4*50 | 1.5 | 3 | 6 | 4 | 50 |
D1.5*3*8*D4*50 | 1.5 | 3 | 8 | 4 | 50 |
D1.5*3*10*D4*50 | 1.5 | 3 | 10 | 4 | 50 |
D1.5*3*12*D4*50 | 1.5 | 3 | 12 | 4 | 50 |
D2*4*8*D4*50 | 2.0 | 4 | 8 | 4 | 50 |
D2*4*10*D4*50 | 2.0 | 4 | 10 | 4 | 50 |
D2*4*12*D4*50 | 2.0 | 4 | 12 | 4 | 50 |
D2.5*5*10*D4*50 | 2.5 | 5 | 10 | 4 | 50 |
D2.5*5*12*D4*50 | 2.5 | 5 | 12 | 4 | 50 |
The defining feature is the elongated neck section between the cutting flutes and the tool shank. This extended neck allows for increased reach and access to deep or recessed areas of the workpiece.
Long neck end mills are designed for deep reach machining applications. The extended neck enables the tool to reach into areas that may be difficult to access with standard end mills, making them suitable for tasks such as deep pocket milling.
The extended neck provides better access to recessed features on the workpiece, allowing for more versatile machining. This is particularly useful when dealing with complex geometries or intricate components.
The extended neck design helps minimize tool deflection during machining. This is crucial for maintaining precision and accuracy, especially in applications that require tight tolerances or fine detail.
Long neck end mills offer increased tool stability when performing deep cutting operations. This stability is essential for achieving consistent results and preventing issues such as chatter or vibration.
Long neck end mills are designed to be versatile and can be used across a variety of materials, including metals, plastics, and composites. This adaptability makes them suitable for diverse machining applications.
Many long neck end mills feature multiple cutting flutes (typically 3 or more), which enhances material removal efficiency and provides better chip evacuation. This design is advantageous for maintaining a smooth machining process.
Long neck end mills are well-suited for contouring and profiling operations, especially in deep or hard-to-reach areas. This makes them valuable tools in industries such as die and mold manufacturing.
The extended neck aids in dissipating heat generated during the machining process. This is particularly beneficial in deep cutting applications where heat buildup can affect tool life and machining accuracy.
Some long neck end mills may incorporate a variable helix or variable pitch design. This feature helps reduce vibrations and chatter during machining, especially at high speeds or when dealing with difficult-to-machine materials.
The primary advantage is the extended reach provided by the long neck design. This allows the end mill to access and machine deep features, cavities, and recessed areas of the workpiece that may be challenging to reach with standard end mills.
Long neck end mills are specifically designed for deep machining applications. Their extended reach enables efficient material removal in deep pockets and recesses, making them ideal for tasks such as mold making and complex part machining.
The extended neck provides better access to recessed or hard-to-reach features on the workpiece. This advantage is crucial in industries like aerospace and automotive, where components often have intricate designs with deep features.
The extended neck helps minimize tool deflection during machining. This is particularly important for maintaining precision and achieving accurate results, especially in applications with tight tolerances or intricate geometries.
Long neck end mills offer enhanced stability during deep cutting operations. The extended neck design contributes to reduced vibrations and improved stability, ensuring consistent and reliable machining performance.
Long neck end mills are versatile and can be used across a variety of materials, including metals, plastics, and composites. This versatility makes them suitable for diverse machining applications in different industries.
Many long neck end mills feature multiple flutes, enhancing chip evacuation and preventing chip buildup during cutting. Efficient chip removal contributes to a smoother machining process and helps avoid potential tool damage.
Long neck end mills are well-suited for contouring and profiling operations, especially in deep or difficult-to-access areas. This makes them valuable tools in applications such as die and mold manufacturing, where complex shapes are common.
The extended neck aids in dissipating heat generated during machining. This is particularly advantageous in deep cutting applications where heat buildup can affect tool life and machining accuracy.
Some long neck end mills incorporate a variable helix or variable pitch design. This feature helps reduce vibrations and chatter during machining, especially at high speeds or when dealing with challenging materials, enhancing overall performance.
The purpose of applying a coating to a carbide Long Neck End Mill is to enhance its performance, durability, and overall effectiveness in various machining operations.
TiN is a popular coating choice for carbide Long Neck End Mill. It offers excellent wear resistance and provides a protective layer on the tool's surface, reducing friction and extending tool life. TiN coatings are effective when machining non-ferrous materials and can enhance performance in general-purpose milling applications.
TiCN coatings offer improved hardness and heat resistance compared to TiN. They are suitable for machining ferrous materials, including steel and cast iron. TiCN coatings provide excellent wear resistance, reduced friction, and increased tool life.
AlTiN coatings are known for their exceptional hardness, high-temperature resistance, and excellent wear resistance. They are suitable for machining abrasive materials, such as hardened steels and stainless steels. AlTiN coatings provide extended tool life and enhanced performance in high-speed machining applications.
DLC coatings offer excellent hardness, low friction, and high lubricity. They are effective when machining aluminum, copper, and non-ferrous materials. DLC coatings can reduce built-up edge and enhance the chip flow, resulting in improved surface finish and reduced cutting forces.
A Long Neck End Mill is a type of cutting tool used in machining and milling operations. It has an extended neck or flute length compared to standard end mills, which allows it to reach into deep cavities or intricate features of a workpiece. This design makes Long Neck End Mills particularly useful for a variety of applications:
The extended reach of a Long Neck End Mill enables it to access recessed areas and deep pockets within a workpiece. This is beneficial for creating complex shapes and features that are not easily accessible with standard tools.
Long Neck End Mills are often employed in 3D machining operations to create intricate and detailed contours on the surface of a workpiece. They can effectively remove material from various angles, allowing for the production of complex geometries.
In the production of molds and dies, where intricate details are essential, Long Neck End Mills are used to accurately machine cavities, cores, and other complex features.
During the prototyping phase of product development, Long Neck End Mills are valuable for creating intricate and small-scale prototypes with precise detailing.
Long Neck End Mills are also employed for engraving and texturing surfaces. The extended flute length helps achieve fine detailing and intricate patterns.
Aerospace parts often require intricate machining due to the complexity of the designs. Long Neck End Mills can reach into deep recesses of aerospace components to produce precision parts.
Medical devices often feature intricate designs and tight tolerances. Long Neck End Mills are used to machine these devices, especially in hard-to-reach areas.
Jewelers use Long Neck End Mills to create detailed patterns and designs on precious metals and gemstones.
In the production of electronic components, Long Neck End Mills are used to machine complex shapes and features on circuit boards and other electronic parts.
Long Neck End Mills play a role in manufacturing intricate automotive components, such as engine parts and transmission components.
A long neck end mill is a type of cutting tool used in milling and machining operations. It features an extended neck or flute, which provides better reach and access to deep or hard-to-reach areas of a workpiece.
Long neck end mills offer several advantages, including improved access to deep cavities, reduced chances of tool deflection, increased rigidity, and better surface finish in complex machining operations.
Long neck end mills are versatile tools capable of machining a wide range of materials, such as metals (aluminum, steel, titanium), plastics, and even some composites. The choice of material depends on the specific type of long neck end mill and its coatings.
Long neck end mills are commonly used for tasks like deep cavity milling, contouring, profiling, and finishing operations. They're suitable for creating intricate shapes, molds, and components in industries such as aerospace, automotive, mold-making, and more.
Consider factors like the material you're machining, the depth of cut required, the desired surface finish, and the machine's capabilities. Choose an appropriate flute length, diameter, number of flutes, and coating to match your project's needs.
A6: A long neck end mill has an extended flute length compared to a standard end mill. This longer flute allows for deeper cuts and better reach into confined areas. Standard end mills are more suitable for shallower cuts and less demanding machining tasks.
Regular maintenance includes cleaning the tool after use, checking for wear or damage, and ensuring proper storage. Using appropriate cutting speeds and feeds, along with proper lubrication and cooling, will help extend the tool's lifespan.
A8: Yes, many long neck end mills can be resharpened to restore their cutting performance. However, excessive resharpening can lead to a reduction in flute length, impacting their ability to reach deep areas effectively.
Solid carbide end mills offer greater hardness, wear resistance, and heat resistance compared to HSS. They're ideal for machining tough materials. HSS end mills are more cost-effective and suitable for less demanding applications.
Yes, long neck end mills can be used in high-speed machining as long as the tool, machine, and workpiece are properly balanced. The reduced risk of deflection and improved rigidity can contribute to successful high-speed machining operations.
Ruiyu is a manufacturer of Carbide Cutting Tools: End Mills, Drills, Routers, Chamfer Mills and Specials.
We have precision detection machine, quality inspectors check cutters every piece to guarantee the quality of the products.
Yes, we have professional technician with rich experience and will deliver the samples for the approval before bulk production.
Yes, we have professional technician with rich experience and will deliver the samples for the approval before bulk production.We can produce according to your drawings; we can supply goods with medium-sized packaging without our logo, then you can repack at your side with your brand packaging; if volume is big, we can pack at our side with your brand packaging.
