Model No. | Flute Diameter (mm) | Flute length (mm) | Shank Diameter (mm) | Overall length (mm) | Model No. | Flute Diameter (mm) | Flute length (mm) | Shank Diameter (mm) | Overall length (mm) | |
D3.1*20*D6*62 | 3.1 | 20 | 6 | 62 | D9.4*47*D10*89 | 9.4 | 47 | 10 | 89 | |
D3.2*20*D6*62 | 3.2 | 20 | 6 | 62 | D9.5*47*D10*89 | 9.5 | 47 | 10 | 89 | |
D3.3*20*D6*62 | 3.3 | 20 | 6 | 62 | D9.6*47*D10*89 | 9.6 | 47 | 10 | 89 | |
D3.4*20*D6*62 | 3.4 | 20 | 6 | 62 | D9.7*47*D10*89 | 9.7 | 47 | 10 | 89 | |
D3.5*20*D6*62 | 3.5 | 20 | 6 | 62 | D9.8*47*D10*89 | 9.8 | 47 | 10 | 89 | |
D3.6*20*D6*62 | 3.6 | 20 | 6 | 62 | D9.9*47*D10*89 | 9.9 | 47 | 10 | 89 | |
D3.7*20*D6*62 | 3.7 | 20 | 6 | 62 | D10*47*D10*89 | 10 | 47 | 10 | 89 | |
D3.8*24*D6*66 | 3.8 | 24 | 6 | 66 | D10.1*55*D12*102 | 10.1 | 55 | 12 | 102 | |
D3.9*24*D6*66 | 3.9 | 24 | 6 | 66 | D10.2*55*D12*102 | 10.2 | 55 | 12 | 102 | |
D4*24*D6*66 | 4 | 24 | 6 | 66 | D10.3*55*D12*102 | 10.3 | 55 | 12 | 102 | |
D4.1*24*D6*66 | 4.1 | 24 | 6 | 66 | D10.4*55*D12*102 | 10.4 | 55 | 12 | 102 | |
D4.2*24*D6*66 | 4.2 | 24 | 6 | 66 | D10.5*55*D12*102 | 10.5 | 55 | 12 | 102 | |
D4.3*24*D6*66 | 4.3 | 24 | 6 | 66 | D10.6*55*D12*102 | 10.6 | 55 | 12 | 102 | |
D4.4*24*D6*66 | 4.4 | 24 | 6 | 66 | D10.7*55*D12*102 | 10.7 | 55 | 12 | 102 | |
D4.5*24*D6*66 | 4.5 | 24 | 6 | 66 | D10.8*55*D12*102 | 10.8 | 55 | 12 | 102 | |
D4.6*24*D6*66 | 4.6 | 24 | 6 | 66 | D10.9*55*D12*102 | 10.9 | 55 | 12 | 102 | |
D4.7*24*D6*66 | 4.7 | 24 | 6 | 66 | D11*55*D12*102 | 11 | 55 | 12 | 102 | |
D4.8*28*D6*66 | 4.8 | 28 | 6 | 66 | D11.1*55*D12*102 | 11.1 | 55 | 12 | 102 | |
D4.9*28*D6*66 | 4.9 | 28 | 6 | 66 | D11.2*55*D12*102 | 11.2 | 55 | 12 | 102 | |
D5*28*D6*66 | 5 | 28 | 6 | 66 | D11.3*55*D12*102 | 11.3 | 55 | 12 | 102 | |
D5.1*28*D6*66 | 5.1 | 28 | 6 | 66 | D11.4*55*D12*102 | 11.4 | 55 | 12 | 102 | |
D5.2*28*D6*66 | 5.2 | 28 | 6 | 66 | D11.5*55*D12*102 | 11.5 | 55 | 12 | 102 | |
D5.3*28*D6*66 | 5.3 | 28 | 6 | 66 | D11.6*55*D12*102 | 11.6 | 55 | 12 | 102 | |
D5.4*28*D6*66 | 5.4 | 28 | 6 | 66 | D11.7*55*D12*102 | 11.7 | 55 | 12 | 102 | |
D5.5*28*D6*66 | 5.5 | 28 | 6 | 66 | D11.8*55*D12*102 | 11.8 | 55 | 12 | 102 | |
D5.6*28*D6*66 | 5.6 | 28 | 6 | 66 | D11.9*55*D12*102 | 11.9 | 55 | 12 | 102 | |
D5.7*28*D6*66 | 5.7 | 28 | 6 | 66 | D12*55*D12*102 | 12 | 55 | 12 | 102 | |
D5.8*28*D6*66 | 5.8 | 28 | 6 | 66 | D12.1*60*D14*107 | 12.1 | 60 | 14 | 107 | |
D5.9*28*D6*66 | 5.9 | 28 | 6 | 66 | D12.2*60*D14*107 | 12.2 | 60 | 14 | 107 | |
D6*28*D6*66 | 6 | 28 | 6 | 66 | D12.3*60*D14*107 | 12.3 | 60 | 14 | 107 | |
D6.1*34*D8*79 | 6.1 | 34 | 8 | 79 | D12.4*60*D14*107 | 12.4 | 60 | 14 | 107 | |
D6.2*34*D8*79 | 6.2 | 34 | 8 | 79 | D12.5*60*D14*107 | 12.5 | 60 | 14 | 107 | |
D6.3*34*D8*79 | 6.3 | 34 | 8 | 79 | D12.6*60*D14*107 | 12.6 | 60 | 14 | 107 | |
D6.4*34*D8*79 | 6.4 | 34 | 8 | 79 | D12.7*60*D14*107 | 12.7 | 60 | 14 | 107 | |
D6.5*34*D8*79 | 6.5 | 34 | 8 | 79 | D12.8*60*D14*107 | 12.8 | 60 | 14 | 107 | |
D6.6*34*D8*79 | 6.6 | 34 | 8 | 79 | D12.9*60*D14*107 | 12.9 | 60 | 14 | 107 | |
D6.7*34*D8*79 | 6.7 | 34 | 8 | 79 | D13*60*D14*107 | 13 | 60 | 14 | 107 | |
D6.8*34*D8*79 | 6.8 | 34 | 8 | 79 | D13.2*60*D14*107 | 13.2 | 60 | 14 | 107 | |
D6.9*34*D8*79 | 6.9 | 34 | 8 | 79 | D13.3*60*D14*107 | 13.3 | 60 | 14 | 107 | |
D7*34*D8*79 | 7 | 34 | 8 | 79 | D13.5*60*D14*107 | 13.5 | 60 | 14 | 107 | |
D7.1*41*D8*79 | 7.1 | 41 | 8 | 79 | D13.7*60*D14*107 | 13.7 | 60 | 14 | 107 | |
D7.2*41*D8*79 | 7.2 | 41 | 8 | 79 | D13.8*60*D14*107 | 13.8 | 60 | 14 | 107 | |
D7.3*41*D8*79 | 7.3 | 41 | 8 | 79 | D14*60*D14*107 | 14 | 60 | 14 | 107 | |
D7.4*41*D8*79 | 7.4 | 41 | 8 | 79 | D14.2*65*D16*115 | 14.2 | 65 | 16 | 115 | |
D7.5*41*D8*79 | 7.5 | 41 | 8 | 79 | D14.3*65*D16*115 | 14.3 | 65 | 16 | 115 | |
D7.6*41*D8*79 | 7.6 | 41 | 8 | 79 | D14.4*65*D16*115 | 14.4 | 65 | 16 | 115 | |
D7.7*41*D8*79 | 7.7 | 41 | 8 | 79 | D14.5*65*D16*115 | 14.5 | 65 | 16 | 115 | |
D7.8*41*D8*79 | 7.8 | 41 | 8 | 79 | D14.7*65*D16*115 | 14.7 | 65 | 16 | 115 | |
D7.9*41*D8*79 | 7.9 | 41 | 8 | 79 | D15*65*D16*115 | 15 | 65 | 16 | 115 | |
D8*41*D8*79 | 8 | 41 | 8 | 79 | D15.2*65*D16*115 | 15.2 | 65 | 16 | 115 | |
D8.1*47*D10*89 | 8.1 | 47 | 10 | 89 | D15.5*65*D16*115 | 15.5 | 65 | 16 | 115 | |
D8.2*47*D10*89 | 8.2 | 47 | 10 | 89 | D15.6*65*D16*115 | 15.6 | 65 | 16 | 115 | |
D8.3*47*D10*89 | 8.3 | 47 | 10 | 89 | D15.7*65*D16*115 | 15.7 | 65 | 16 | 115 | |
D8.4*47*D10*89 | 8.4 | 47 | 10 | 89 | D15.8*65*D16*115 | 15.8 | 65 | 16 | 115 | |
D8.5*47*D10*89 | 8.5 | 47 | 10 | 89 | D16*65*D16*115 | 16 | 65 | 16 | 115 | |
D8.6*47*D10*89 | 8.6 | 47 | 10 | 89 | D16.5*73*D18*123 | 16.5 | 73 | 18 | 123 | |
D8.7*47*D10*89 | 8.7 | 47 | 10 | 89 | D17*73*D18*123 | 17 | 73 | 18 | 123 | |
D8.8*47*D10*89 | 8.8 | 47 | 10 | 89 | D17.5*73*D18*123 | 17.5 | 73 | 18 | 123 | |
D8.9*47*D10*89 | 8.9 | 47 | 10 | 89 | D18*73*D18*123 | 18 | 73 | 18 | 123 | |
D9*47*D10*89 | 9 | 47 | 10 | 89 | D18.5*79*D20*131 | 18.5 | 79 | 20 | 131 | |
D9.1*47*D10*89 | 9.1 | 47 | 10 | 89 | D19*79*D20*131 | 19 | 79 | 20 | 131 | |
D9.2*47*D10*89 | 9.2 | 47 | 10 | 89 | D19.5*79*D20*131 | 19.5 | 79 | 20 | 131 | |
D9.3*47*D10*89 | 9.3 | 47 | 10 | 89 | D20*79*D20*131 | 20 | 79 | 20 | 131 |
Model No. | Flute Diameter (mm) | Flute length (mm) | Shank Diameter (mm) | Overall length (mm) | Model No. | Flute Diameter (mm) | Flute length (mm) | Shank Diameter (mm) | Overall length (mm) | |
D3.1*28*D6*66 | 3.1 | 28 | 6 | 66 | D9.4*61*D10*103 | 9.4 | 61 | 10 | 103 | |
D3.2*28*D6*66 | 3.2 | 28 | 6 | 66 | D9.5*61*D10*103 | 9.5 | 61 | 10 | 103 | |
D3.3*28*D6*66 | 3.3 | 28 | 6 | 66 | D9.6*61*D10*103 | 9.6 | 61 | 10 | 103 | |
D3.4*28*D6*66 | 3.4 | 28 | 6 | 66 | D9.7*61*D10*103 | 9.7 | 61 | 10 | 103 | |
D3.5*28*D6*66 | 3.5 | 28 | 6 | 66 | D9.8*61*D10*103 | 9.8 | 61 | 10 | 103 | |
D3.6*28*D6*66 | 3.6 | 28 | 6 | 66 | D9.9*61*D10*103 | 9.9 | 61 | 10 | 103 | |
D3.7*28*D6*66 | 3.7 | 28 | 6 | 66 | D10*61*D10*103 | 10 | 61 | 10 | 103 | |
D3.8*36*D6*74 | 3.8 | 36 | 6 | 74 | D10.1*71*D12*118 | 10.1 | 71 | 12 | 118 | |
D3.9*36*D6*74 | 3.9 | 36 | 6 | 74 | D10.2*71*D12*118 | 10.2 | 71 | 12 | 118 | |
D4*36*D6*74 | 4 | 36 | 6 | 74 | D10.3*71*D12*118 | 10.3 | 71 | 12 | 118 | |
D4.1*36*D6*74 | 4.1 | 36 | 6 | 74 | D10.4*71*D12*118 | 10.4 | 71 | 12 | 118 | |
D4.2*36*D6*74 | 4.2 | 36 | 6 | 74 | D10.5*71*D12*118 | 10.5 | 71 | 12 | 118 | |
D4.3*36*D6*74 | 4.3 | 36 | 6 | 74 | D10.6*71*D12*118 | 10.6 | 71 | 12 | 118 | |
D4.4*36*D6*74 | 4.4 | 36 | 6 | 74 | D10.7*71*D12*118 | 10.7 | 71 | 12 | 118 | |
D4.5*36*D6*74 | 4.5 | 36 | 6 | 74 | D10.8*71*D12*118 | 10.8 | 71 | 12 | 118 | |
D4.6*36*D6*74 | 4.6 | 36 | 6 | 74 | D10.9*71*D12*118 | 10.9 | 71 | 12 | 118 | |
D4.7*36*D6*82 | 4.7 | 36 | 6 | 82 | D11*71*D12*118 | 11 | 71 | 12 | 118 | |
D4.8*44*D6*82 | 4.8 | 44 | 6 | 82 | D11.1*71*D12*118 | 11.1 | 71 | 12 | 118 | |
D4.9*44*D6*82 | 4.9 | 44 | 6 | 82 | D11.2*71*D12*118 | 11.2 | 71 | 12 | 118 | |
D5*44*D6*82 | 5 | 44 | 6 | 82 | D11.3*71*D12*118 | 11.3 | 71 | 12 | 118 | |
D5.1*44*D6*82 | 5.1 | 44 | 6 | 82 | D11.4*71*D12*118 | 11.4 | 71 | 12 | 118 | |
D5.2*44*D6*82 | 5.2 | 44 | 6 | 82 | D11.5*71*D12*118 | 11.5 | 71 | 12 | 118 | |
D5.3*44*D6*82 | 5.3 | 44 | 6 | 82 | D11.6*71*D12*118 | 11.6 | 71 | 12 | 118 | |
D5.4*44*D6*82 | 5.4 | 44 | 6 | 82 | D11.7*71*D12*118 | 11.7 | 71 | 12 | 118 | |
D5.5*44*D6*82 | 5.5 | 44 | 6 | 82 | D11.8*71*D12*118 | 11.8 | 71 | 12 | 118 | |
D5.6*44*D6*82 | 5.6 | 44 | 6 | 82 | D11.9*71*D12*118 | 11.9 | 71 | 12 | 118 | |
D5.7*44*D6*82 | 5.7 | 44 | 6 | 82 | D12*71*D12*118 | 12 | 71 | 12 | 118 | |
D5.8*44*D6*82 | 5.8 | 44 | 6 | 82 | D12.1*77*D14*124 | 12.1 | 77 | 14 | 124 | |
D5.9*44*D6*82 | 5.9 | 44 | 6 | 82 | D12.2*77*D14*124 | 12.2 | 77 | 14 | 124 | |
D6*44*D6*82 | 6 | 44 | 6 | 82 | D12.3*77*D14*124 | 12.3 | 77 | 14 | 124 | |
D6.1*53*D8*91 | 6.1 | 53 | 8 | 91 | D12.4*77*D14*124 | 12.4 | 77 | 14 | 124 | |
D6.2*53*D8*91 | 6.2 | 53 | 8 | 91 | D12.5*77*D14*124 | 12.5 | 77 | 14 | 124 | |
D6.3*53*D8*91 | 6.3 | 53 | 8 | 91 | D12.6*77*D14*124 | 12.6 | 77 | 14 | 124 | |
D6.4*53*D8*91 | 6.4 | 53 | 8 | 91 | D12.7*77*D14*124 | 12.7 | 77 | 14 | 124 | |
D6.5*53*D8*91 | 6.5 | 53 | 8 | 91 | D12.8*77*D14*124 | 12.8 | 77 | 14 | 124 | |
D6.6*53*D8*91 | 6.6 | 53 | 8 | 91 | D12.9*77*D14*124 | 12.9 | 77 | 14 | 124 | |
D6.7*53*D8*91 | 6.7 | 53 | 8 | 91 | D13*77*D14*124 | 13 | 77 | 14 | 124 | |
D6.8*53*D8*91 | 6.8 | 53 | 8 | 91 | D13.2*77*D14*124 | 13.2 | 77 | 14 | 124 | |
D6.9*53*D8*91 | 6.9 | 53 | 8 | 91 | D13.3*77*D14*124 | 13.3 | 77 | 14 | 124 | |
D7*53*D8*91 | 7 | 53 | 8 | 91 | D13.5*77*D14*124 | 13.5 | 77 | 14 | 124 | |
D7.1*53*D8*91 | 7.1 | 53 | 8 | 91 | D13.7*77*D14*124 | 13.7 | 77 | 14 | 124 | |
D7.2*53*D8*91 | 7.2 | 53 | 8 | 91 | D13.8*77*D14*124 | 13.8 | 77 | 14 | 124 | |
D7.3*53*D8*91 | 7.3 | 53 | 8 | 91 | D14*77*D14*124 | 14 | 77 | 14 | 124 | |
D7.4*53*D8*91 | 7.4 | 53 | 8 | 91 | D14.2*83*D16*133 | 14.2 | 83 | 16 | 133 | |
D7.5*53*D8*91 | 7.5 | 53 | 8 | 91 | D14.3*83*D16*133 | 14.3 | 83 | 16 | 133 | |
D7.6*53*D8*91 | 7.6 | 53 | 8 | 91 | D14.4*83*D16*133 | 14.4 | 83 | 16 | 133 | |
D7.7*53*D8*91 | 7.7 | 53 | 8 | 91 | D14.5*83*D16*133 | 14.5 | 83 | 16 | 133 | |
D7.8*53*D8*91 | 7.8 | 53 | 8 | 91 | D14.7*83*D16*133 | 14.7 | 83 | 16 | 133 | |
D7.9*53*D8*91 | 7.9 | 53 | 8 | 91 | D15*83*D16*133 | 15 | 83 | 16 | 133 | |
D8*53*D8*91 | 8 | 53 | 8 | 91 | D15.2*83*D16*133 | 15.2 | 83 | 16 | 133 | |
D8.1*61*D10*103 | 8.1 | 61 | 10 | 103 | D15.5*83*D16*133 | 15.5 | 83 | 16 | 133 | |
D8.2*61*D10*103 | 8.2 | 61 | 10 | 103 | D15.6*83*D16*133 | 15.6 | 83 | 16 | 133 | |
D8.3*61*D10*103 | 8.3 | 61 | 10 | 103 | D15.7*83*D16*133 | 15.7 | 83 | 16 | 133 | |
D8.4*61*D10*103 | 8.4 | 61 | 10 | 103 | D15.8*83*D16*133 | 15.8 | 83 | 16 | 133 | |
D8.5*61*D10*103 | 8.5 | 61 | 10 | 103 | D16*83*D16*133 | 16 | 83 | 16 | 133 | |
D8.6*61*D10*103 | 8.6 | 61 | 10 | 103 | D16.5*93*D18*143 | 16.5 | 93 | 18 | 143 | |
D8.7*61*D10*103 | 8.7 | 61 | 10 | 103 | D17*93*D18*143 | 17 | 93 | 18 | 143 | |
D8.8*61*D10*103 | 8.8 | 61 | 10 | 103 | D17.5*93*D18*143 | 17.5 | 93 | 18 | 143 | |
D8.9*61*D10*103 | 8.9 | 61 | 10 | 103 | D18*93*D18*143 | 18 | 93 | 18 | 143 | |
D9*61*D10*103 | 9 | 61 | 10 | 103 | D18.5*101*D20*153 | 18.5 | 101 | 20 | 153 | |
D9.1*61*D10*103 | 9.1 | 61 | 10 | 103 | D19*101*D20*153 | 19 | 101 | 20 | 153 | |
D9.2*61*D10*103 | 9.2 | 61 | 10 | 103 | D19.5*101*D20*153 | 19.5 | 101 | 20 | 153 | |
D9.3*61*D10*103 | 9.3 | 61 | 10 | 103 | D20*101*D20*153 | 20 | 101 | 20 | 153 |
Carbide drill bits are made of tungsten carbide, which is exceptionally hard and durable. This hardness allows the bits to maintain their sharp cutting edges for a long time, even when drilling through dense and abrasive wood materials.
Carbide bits retain their sharpness longer than traditional steel bits. This sharp cutting edge ensures clean and precise holes in wood without splintering or chipping, resulting in professional-looking finishes.
Carbide drill bits for wood are versatile and can be used for various woodworking applications, including drilling holes for screws, dowels, and other fasteners, as well as creating decorative details and designs.
Carbide bits are designed with efficient flute shapes that help in quick and effective removal of wood chips. Proper chip evacuation prevents clogging and ensures smooth drilling operations.
Carbide drill bits can withstand high temperatures generated during drilling without losing their hardness or becoming brittle. This heat resistance is crucial for continuous and prolonged use in woodworking projects.
Carbide bits have low friction coefficients, allowing them to glide smoothly through wood. Reduced friction leads to less heat generation during drilling, prolonging the lifespan of the bit and ensuring cleaner holes.
Carbide drill bits provide high precision and accuracy when drilling into wood. They can create holes with consistent sizes and depths, making them ideal for intricate woodworking tasks that demand precision.
Due to their hardness and durability, carbide drill bits have a longer lifespan compared to traditional steel bits. This longevity results in fewer replacements, saving both time and money for woodworkers.
Carbide bits come in various specialized designs, such as spade bits, Forstner bits, and auger bits, each tailored for specific woodworking applications. These specialized designs allow woodworkers to achieve specific hole shapes and sizes.
Carbide drill bits are compatible with a wide range of power tools, including drills and drill presses. Their compatibility with various woodworking machinery makes them convenient and versatile for woodworkers.
Carbide drill bits can be customized with different tip geometries and angles to suit specific woodworking requirements. Customization ensures optimal performance for various wood types and project needs.
Carbide drill bits retain their sharpness much longer than traditional steel bits. This extended sharpness ensures cleaner and more precise holes in wood without splintering or tearing, even after prolonged use.
Carbide drill bits are extremely durable due to their hardness. They can withstand the abrasive nature of wood, making them ideal for drilling through hardwoods and dense wooden materials without losing their cutting edge.
Carbide bits provide high precision and accuracy when drilling into wood. They create holes with consistent sizes and depths, allowing woodworkers to achieve precise fits for dowels, screws, and other fasteners.
Carbide drill bits come in various designs, including twist bits, spade bits, Forstner bits, and auger bits. This variety allows woodworkers to choose the right bit for specific tasks, making them versatile tools for a wide range of woodworking applications.
Carbide bits are designed with efficient flute shapes that facilitate quick and effective removal of wood chips. Proper chip evacuation prevents clogging, ensuring smooth drilling operations and minimizing heat buildup.
Carbide bits have low friction coefficients, enabling them to glide smoothly through wood. Reduced friction results in less heat generation during drilling, which is beneficial for both the bit's lifespan and the quality of the drilled hole.
Carbide drill bits are particularly effective for drilling into hardwoods, which are dense and challenging to work with. Their hardness allows them to cut through hardwoods with ease, making them invaluable for various woodworking projects.
Carbide drill bits are compatible with a wide range of power tools, including drills, drill presses, and routers. This compatibility allows woodworkers to use them with different machinery, enhancing their flexibility and usability in the workshop.
Due to their sharpness and precision, carbide drill bits create cleaner holes with smooth edges. This clean-cut finish reduces the need for extensive sanding or other finishing processes, saving time and effort in woodworking projects.
Carbide bits require less frequent sharpening or replacement compared to traditional steel bits. Their long lifespan and durability result in reduced maintenance efforts and costs for woodworkers over time.
Carbide drill bits provide woodworkers with the tools needed to achieve professional-quality results. Whether for DIY projects or professional woodworking tasks, the clean and precise holes they create contribute to the overall craftsmanship of the finished product.
The purpose of applying a coating to a Carbide Drill Bits For Wood is to enhance its performance, durability, and overall effectiveness in various machining operations.
TiN is a popular coating choice for Carbide Drill Bits For Wood. It offers excellent wear resistance and provides a protective layer on the tool's surface, reducing friction and extending tool life. TiN coatings are effective when machining non-ferrous materials and can enhance performance in general-purpose milling applications.
TiCN coatings offer improved hardness and heat resistance compared to TiN. They are suitable for machining ferrous materials, including steel and cast iron. TiCN coatings provide excellent wear resistance, reduced friction, and increased tool life.
AlTiN coatings are known for their exceptional hardness, high-temperature resistance, and excellent wear resistance. They are suitable for machining abrasive materials, such as hardened steels and stainless steels. AlTiN coatings provide extended tool life and enhanced performance in high-speed machining applications.
DLC coatings offer excellent hardness, low friction, and high lubricity. They are effective when machining aluminum, copper, and non-ferrous materials. DLC coatings can reduce built-up edge and enhance the chip flow, resulting in improved surface finish and reduced cutting forces.
Carbide drill bits are used for drilling holes in wood for various purposes, such as creating holes for dowels, screws, and bolts. They provide precise and clean holes, ensuring a secure fit for fasteners.
Woodworkers use carbide drill bits to create holes for joinery techniques like mortise and tenon joints. These joints are fundamental in woodworking for strong and durable connections between wooden pieces.
Carbide drill bits are essential in furniture making for drilling holes for assembly. Whether it's for attaching table legs, assembling cabinets, or connecting wooden components, carbide bits provide accuracy and consistency.
In cabinetmaking, carbide drill bits are used for drilling holes for hinges, handles, knobs, and shelf supports. They create clean holes without splintering, ensuring a professional finish for cabinets and drawers.
Woodturners use carbide bits for shaping and hollowing wood on a lathe. Carbide cutters are effective for creating intricate designs and patterns on turned wooden objects like bowls, vases, and spindles.
Carbide drill bits are used in wood carving applications to create detailed designs and relief patterns. They allow woodworkers to carve intricate shapes and textures in wood surfaces.
Carbide bits are used with router jigs to create intricate patterns and decorative edges on wooden surfaces. These bits are particularly useful for making ornamental moldings and trim pieces.
Carbide bits are employed for inlay work, where small decorative elements or materials are embedded into the wood surface. Carbide bits create precise recesses for inlay materials like metal, shell, or other woods.
Carbide bits are used in making wooden toys, especially for creating holes for axles, wheels, and other moving parts. They provide accuracy, ensuring smooth movement for toy components.
Sculptors use carbide drill bits to remove material and create intricate details in wooden sculptures. Carbide bits offer control and precision in shaping wood for artistic expression.
Carbide bits are commonly used for drilling dowel holes. Dowels are used for accurate alignment and strong joints in woodworking projects, and carbide bits ensure precise holes for dowel insertion.
Carbide drill bits are employed in various custom woodworking projects, including creating personalized signs, decorative wooden boxes, and unique home décor items. Their precision and versatility make them invaluable in these creative applications.
A carbide drill bit is a cutting tool made from carbide, a hard and durable material. Carbide drill bits are ideal for woodworking due to their sharpness, longevity, and ability to cut through various types of wood cleanly and accurately.
Carbide drill bits can be used with both hand drills and power tools. They are compatible with a wide range of woodworking tools, making them versatile for different woodworking applications.
Yes, carbide drill bits are suitable for drilling both hardwoods (such as oak, maple, and walnut) and softwoods (such as pine, cedar, and fir). Their sharp cutting edges allow them to cut through various wood densities with ease and precision.
Carbide drill bits are incredibly durable and maintain their sharpness for a long time. They require less frequent sharpening compared to traditional steel bits. The frequency of sharpening depends on usage; for heavy use, they may need sharpening after a significant period of use.
Yes, carbide drill bits can be used for drilling deep holes in wood. However, it's important to use the appropriate bit design (such as auger bits or spade bits) and ensure proper chip evacuation to prevent overheating and maintain efficient drilling.
Yes, there are various types of carbide drill bits designed for specific woodworking tasks. For example, twist bits are versatile for general drilling, while Forstner bits are ideal for creating flat-bottomed holes. Specialty bits like plug cutters and countersink bits are also available for specific applications.
Yes, carbide drill bits are suitable for woodworking projects involving inlays and detailed carvings. They provide the precision required for creating intricate designs and accurate recesses for inlay materials.
Carbide drill bits are relatively easy to clean. Regular cleaning with a brush or compressed air helps remove wood chips and debris. While they are durable, proper maintenance includes using the correct drilling speed, avoiding excessive heat, and ensuring efficient chip removal for optimal performance.
Yes, carbide drill bits can be used for drilling through laminated wood or plywood. Their sharp edges and durability make them effective for drilling through composite materials without splintering or damaging the surface. Proper drilling techniques and appropriate bit selection are essential for clean holes in laminated wood.
Yes, we are facotry. Founded in 2004,Ruiyu Tools has established itself as a trusted provider of high-quality drill bits, end mills, and other non-standard tools.
Before purchasing, please contact us to confirm model No. and drawings to avoid any misunderstanding.
Yes.We can supply OEM&ODM and make customized design for any specific application.
We suggest you ording a sample. And you can also send us email with detailed photos and specifications for checking if you cannot get enough information in the product page.
Non-standard tools 5-10 Working days,Standard tools usually 1-2 days.
Consult Your Ruiyu Carbide Tools Experts
We help you avoid the pitfalls to deliver the quality and value your Carbide Tools needs, on-time and on-budget.
