Solid Carbide 3 Flute Corner Radius End Mill
3 Flute
Spiral
High Speed Cutting
Aluminum, Copper, Cast Iron, Alloy Steel, Tool Steel,Stainless Steel, High-temp Alloys, Titanium Alloys, Non-ferrous Alloys
TiAlN, TiSiN, Nano
0.005-0.01
Stub, Standard, Extra-Long,38-330mm
| Quantity: | |
|---|---|
Model No. | Flute Diameter (mm) | Radius (mm) | Flute length (mm) | Shank Diameter (mm) | Overall length (mm) |
D2*R0.5*6*D4*50 | 2.0 | 0.5 | 6 | 4 | 50 |
D3*R0.2*8*D4*50 | 3.0 | 0.2 | 8 | 4 | 50 |
D3*R0.5*8*D4*50 | 3.0 | 0.5 | 8 | 4 | 50 |
D4*R0.5*10*D4*50 | 4.0 | R0.5 | 10 | 4 | 50 |
D4*R1*10*D4*50 | 4.0 | R1 | 10 | 4 | 50 |
D6*R0.5*15*D6*50 | 6.0 | R0.5 | 15 | 6 | 50 |
D6*R1*15*D6*50 | 6.0 | R1 | 15 | 6 | 50 |
D8*R0.5*20*D8*60 | 8.0 | R0.5 | 20 | 8 | 60 |
D8*R1*20*D8*60 | 8.0 | R1 | 20 | 8 | 60 |
D8*R1.5*20*D8*60 | 8.0 | R1.5 | 20 | 8 | 60 |
D10*R0.5*25*D10*75 | 10.0 | R0.5 | 25 | 10 | 75 |
D10*R1*25*D10*75 | 10.0 | R1 | 25 | 10 | 75 |
D10*R1.5*25*D10*75 | 10.0 | R1.5 | 25 | 10 | 75 |
D12*R0.5*30*D12*75 | 12.0 | R0.5 | 30 | 12 | 75 |
D12*R1*30*D12*75 | 12.0 | R1 | 30 | 12 | 75 |
D12*R1.5*30*D12*75 | 12.0 | R1.5 | 30 | 12 | 75 |
D12*R2*30*D12*75 | 12.0 | R2 | 30 | 12 | 75 |
Model No. | Flute Diameter (mm) | Radius (mm) | Flute length (mm) | Shank Diameter (mm) | Overall length (mm) |
D2*R0.5*6*D4*75 | 2.0 | R0.5 | 6 | 4 | 75 |
D3*R0.5*8*D4*75 | 3.0 | R0.5 | 8 | 4 | 75 |
D4*R0.5*11*D4*75 | 4.0 | R0.5 | 11 | 4 | 75 |
D4*R1*11*D4*75 | 4.0 | R1 | 11 | 4 | 75 |
D4*R0.5*11*D4*100 | 4.0 | R0.5 | 11 | 4 | 100 |
D4*R1*11*D4*100 | 4.0 | R1 | 11 | 4 | 100 |
D6*R0.5*15*D6*75 | 6.0 | R0.5 | 15 | 6 | 75 |
D6*R1*15*D6*75 | 6.0 | R1 | 15 | 6 | 75 |
D6*R0.5*15*D6*100 | 6.0 | R0.5 | 15 | 6 | 100 |
D6*R1*15*D6*100 | 6.0 | R1 | 15 | 6 | 100 |
D8*R0.5*20*D8*75 | 8.0 | R0.5 | 20 | 8 | 75 |
D8*R1*20*D8*75 | 8.0 | R1 | 20 | 8 | 75 |
D8*R1.5*20*D8*75 | 8.0 | R1.5 | 20 | 8 | 75 |
D10*R0.5*25*D10*100 | 10.0 | R0.5 | 25 | 10 | 100 |
D10*R1*25*D10*100 | 10.0 | R1 | 25 | 10 | 100 |
D10*R1.5*25*D10*100 | 10.0 | R1.5 | 25 | 10 | 100 |
D12*R0.5*30*D12*100 | 12.0 | R0.5 | 30 | 12 | 100 |
D12*R1*30*D12*100 | 12.0 | R1 | 30 | 12 | 100 |
D12*R1.5*30*D12*100 | 12.0 | R1.5 | 30 | 12 | 100 |
D12*R2*30*D12*100 | 12.0 | R2 | 30 | 12 | 100 |
The end mill is equipped with three cutting flutes or edges. This design provides a balance between material removal efficiency, chip evacuation, and stability during cutting operations.
Similar to the 4-flute version, a 3-flute corner radius end mill features a rounded corner at the tool's end. This radius serves to reduce stress concentrations, improve surface finish, and extend tool life by minimizing wear at the tool's corners.
The 3-flute design is suitable for machining various materials, including metals, plastics, and composites. Its versatility makes it a viable option for different applications across different workpiece materials.
The three flutes facilitate efficient chip evacuation during cutting operations. This helps prevent chip buildup and ensures a smoother machining process, reducing the risk of tool damage and improving overall efficiency.
A 3-flute corner radius end mill is versatile and can be used for a range of milling applications, including roughing, finishing, and slotting. Its design allows for adaptability to different machining scenarios.
The corner radius contributes to a better surface finish on the machined part. This is beneficial in applications where a smooth surface is crucial, potentially reducing the need for additional finishing steps.
The presence of a corner radius allows the end mill to adapt to contours and curved surfaces effectively. This makes it suitable for tasks requiring machining of intricate shapes and profiles.
The three-flute design helps minimize chatter and vibrations during cutting, enhancing the precision of the machining process. This is particularly important for achieving accurate cuts and maintaining the integrity of the workpiece.
The design of the end mill, with three flutes and a corner radius, makes it well-suited for high-speed machining operations. It can efficiently remove material at elevated cutting speeds, contributing to increased productivity.
The combination of three flutes and a corner radius results in balanced performance, providing a good compromise between material removal rates, tool life, and surface finish. This makes the end mill suitable for a variety of applications.
The three flutes provide a balanced compromise between material removal rates, surface finish, and tool stability. This balance makes the end mill versatile and suitable for a wide range of milling tasks.
The design of the 3-flute corner radius end mill allows it to effectively machine different materials, including metals, plastics, and composites. This versatility makes it a valuable tool for various machining applications.
The three flutes facilitate efficient chip evacuation during cutting. This helps prevent chip congestion, reducing the risk of tool damage and ensuring a smoother machining process.
The three-flute configuration contributes to minimizing chatter and vibrations during cutting operations. This is essential for achieving precise cuts and maintaining the integrity of the workpiece.
The presence of a corner radius at the tool's end enables effective adaptation to contours and curved surfaces. This feature is particularly advantageous in applications that involve machining intricate shapes and profiles.
The corner radius assists in achieving a better surface finish on the machined part. This is beneficial in applications where a smooth and high-quality surface is essential, potentially reducing the need for additional finishing steps.
The balanced design of the 3-flute end mill helps distribute cutting forces evenly, reducing tool wear and extending the overall lifespan of the tool. This results in cost savings through fewer tool changes.
The tool is well-suited for high-speed machining operations, allowing for efficient material removal at elevated cutting speeds. This capability contributes to increased productivity in manufacturing processes.
The corner radius at the tool's end serves to reduce stress concentrations, minimizing wear and extending tool life. It also contributes to improved performance in terms of surface finish and adaptability to different geometries.
The combination of extended tool life, versatility, and efficient performance makes the 3-flute corner radius end mill a cost-effective choice for machining operations. Reduced tool changes and improved cutting efficiency contribute to overall cost savings.
The purpose of applying a coating to a carbide 3 Flute Corner Radius End Mill is to enhance its performance, durability, and overall effectiveness in various machining operations.
TiN is a popular coating choice for carbide 3 Flute Corner Radius End Mill. It offers excellent wear resistance and provides a protective layer on the tool's surface, reducing friction and extending tool life. TiN coatings are effective when machining non-ferrous materials and can enhance performance in general-purpose milling applications.
TiCN coatings offer improved hardness and heat resistance compared to TiN. They are suitable for machining ferrous materials, including steel and cast iron. TiCN coatings provide excellent wear resistance, reduced friction, and increased tool life.
AlTiN coatings are known for their exceptional hardness, high-temperature resistance, and excellent wear resistance. They are suitable for machining abrasive materials, such as hardened steels and stainless steels. AlTiN coatings provide extended tool life and enhanced performance in high-speed machining applications.
DLC coatings offer excellent hardness, low friction, and high lubricity. They are effective when machining aluminum, copper, and non-ferrous materials. DLC coatings can reduce built-up edge and enhance the chip flow, resulting in improved surface finish and reduced cutting forces.
The unique design of the 3 Flute Corner Radius End Mill offers several key advantages that make it a preferred choice for various machining operations. With three cutting edges, the tool efficiently disperses cutting forces, resulting in reduced vibration and improved stability. This allows for higher feed rates, shorter cycle times, and ultimately, enhanced productivity. The rounded corner radius minimizes chipping, enabling the creation of intricate contours and profiles with precision and finesse.
In the aerospace sector, where precision and quality are paramount, the Corner Radius End Mill plays a vital role in machining turbine blades, engine components, and other intricate parts. Its ability to create complex profiles and tight tolerances ensures the highest level of performance in critical aerospace applications.
Automotive manufacturing demands efficiency without compromising on the quality of the final product. The 3 Flute Corner Radius End Mill is instrumental in producing molds, dies, and parts with intricate contours, contributing to the overall performance and aesthetics of vehicles.
The medical industry relies on precision machining for the production of implantable devices and surgical instruments. The Corner Radius End Mill excels in this realm, enabling the creation of intricate features on biocompatible materials, adhering to the strictest standards of quality and safety.
Mold and die making is another domain where the Corner Radius End Mill shines. By eliminating stress concentration and reducing sharp corners, this tool prolongs tool life, enhances part accuracy, and contributes to efficient and reliable mold production.
A 3 Flute Corner Radius End Mill is a type of cutting tool commonly used in machining and milling operations. It features three cutting edges (flutes) and incorporates a rounded corner (radius) at the bottom of the tool, which helps reduce stress concentrations and enhance tool longevity.
Utilizing a 3 Flute Corner Radius End Mill offers advantages such as improved tool strength, reduced risk of chipping, extended tool life, smoother surface finishes, and the ability to perform intricate contouring and profiling tasks.
Distinct from standard end mills featuring sharp corners, the 3 Flute Corner Radius End Mill boasts a rounded corner design that disperses cutting forces evenly, decreasing the chances of corner breakage. This design is particularly advantageous when machining harder materials or undertaking demanding machining operations.
A 3 Flute Corner Radius End Mill is versatile and suitable for machining a broad range of materials, including metals (such as steel, aluminum, and stainless steel), plastics, and composites. Its rounded corner design makes it especially effective for materials prone to chipping or fracturing with tools that have sharp corners.
The 3 Flute Corner Radius End Mill is well-suited for various operations, including slotting, contouring, profiling, and ramping. It offers versatility and can handle both roughing and finishing tasks with precision.
When choosing a 3 Flute Corner Radius End Mill, factors such as the material being machined, desired surface finish, cutting speed and feed rate, tool diameter and length, and specific application requirements should be taken into account.
To extend the tool's lifespan, ensure proper lubrication, operate within recommended cutting parameters, avoid excessive radial engagement, and conduct routine inspections for signs of wear or damage.
The 3 Flute Corner Radius End Mill finds applications in aerospace engineering, automotive manufacturing, medical device production, mold and die making, and various other industries that demand precision and quality.
Yes, you can resharpen a 3 Flute Corner Radius End Mill using appropriate tool grinding equipment. However, excessive resharpening can alter the tool's geometry and performance, so it's advisable to adhere to manufacturer guidelines.
Ruiyu is a manufacturer of Carbide Cutting Tools: End Mills, Drills, Routers, Chamfer Mills and Specials.
